Nitrogen Equipment
The nitrogen line of products is broken into two main categories: Direct Fire Nitrogen Equipment and Non-Fired Nitrogen Equipment. We can design and customized truck mounted Nitrogen units or skid mounted Nitrogen units.
Fired Nitrogren Unit
The UE Manufacturing direct fired nitrogen truck is designed for the pumping of gaseous nitrogen at high rates of up to or in excess of 1 million SCFH. (standard cubic feet/hour) The nitrogen side of the pumps are powered with up to 1500 horsepower and equipped with a cryogenic centrifugal boost pump, cryogenic high pressure quintuplex pump, direct fired vaporizer system among other necessary components.
We provide the options to have the units built via trailer, skid or chassis mounted versions. The unit may either be controlled locally or remotely from a hand held pump controller. The units offer data acquisition software capabilities in addition to other features that will allow you to obtain the high rate performance desired for any given N2 job. Let us help custom design or build to standard spec the LN2 pumping needs you have.
A skid mounted, nitrogen pump manufactured by UE Manufacturing.
A skid mounted, nitrogen pump
manufactured by UE Manufacturing.
Non-Fired Nitrogren Unit
The UEM skid mounted, liquid nitrogen pumping unit comes equipped with a non-fired vaporizer system. The skid incorporates a crash cage, liquid nitrogen triplex pump, centrifugal boost pump and liquid nitrogen non-fired vaporizer.
Dependent upon customer specific needs the diesel engine is determined by amount of horsepower desired. The diesel engine is used to drive the hydraulic system and in turn, the unit utilizes the waste heat from engine the coolant system and hydraulic oil circuits to vaporize liquid nitrogen – a non-fired vaporization system. These can be designed for flow rates of up to 360K SCFH at max pressures of 15,000 lbs.
